ORSR Single Antenna Reader


Long Range HDX PIT Tag Reader.


Drives one antenna from 4″ diameter to 200′ across.


Next generation high performance single antenna LF HDX RFID reader, ISO 11784 compatible. All connectors are waterproof on the watertight gasketed enclosure. The antenna is tuned by pressing a button on the front panel. Readers automatically synchronize using GNSS signals (GPS, GLONASS, Galileo, QZSS) or can be connected with CAT5 cable.  Use with loop antennas up to 60 meters wide.

  • GNSS receiver for location, accurate time of day and reader synchronization
  • Pushbutton antenna tuning whether using automatic or manual capacitors
  • Reader stops when the supply voltage is low to prevent battery damage
  • Automatically restarts when the supply voltage level returns

Includes waterproof antenna connector, GNSS antenna, USB-to-serial cable and power cable.

Available with internal Bluetooth interface.

Requires either standard or autotuning capacitors sold separately.

Overall dimensions: 10.5″ x 5″ x 4″, 26.5 x 12.5 x 10 cm

Learn more about this reader here.
